SPECIFICATIONS:
CAPACITY ---------------------------- 13 1/2 in ROUND AT 90°
22 in FLAT AT 90°
13 in H X 16 in W TUBE AT 90°
13 1/2 in ROUND AT 45°
14 in FLAT AT 45°
13 in H X 13 in W TUBE AT 45°
BLADE SPEEDS ------------------------ 75-195 FPM
BLADE SIZE -------------------------- 15' X 1.25" X .042
HEAD PRESSURE ----------------------- HYDRAULIC CYLINDER
VISE -------------------------------- QUICK ADJUSTING SCREW TYPE
SHUT OFF ---------------------------- AUTOMATIC
MOTOR ------------------------------- 2 H.P. 220 VOLT
SINGLE PHASE, 3 PHASE
220/440/460/480/575
SHIPPING WEIGHT --------------------- 1,250 LBS.
SIZE - TABLE HEIGHT ----------------- 29.375"
LENGTH ----------------------- 90"
WIDTH ------------------------ 44"
HEIGHT ----------------------- 50"
SEALED OIL BATH WORM GEAR ----------- STANDARD
REMOVABLE CHIP TRAY ----------------- STANDARD
AIR COOLING SYSTEM ------------------ STANDARD
TABLE BACK EXTENSION 7 in ------------- STANDARD
CONSTRUCTION ------------------------ HEAVY STEEL, WELDED AND MACHINED FOR ACCURACY AND DURABILITY
FEATURES:
*HEAD MOVES LEFT OR RIGHT FOR ANGLE CUTTING
*BUILT-IN PROTRACTOR FOR FAST AND ACCURATE SELECTION OF ANGLES
*STOCK REMAINS IN ONE POSITION FOR ALL CUTS
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
* Stock gauge with micro-adjuster...........................................................................................................................$125.00
* 5 ft. Stock support stand with 4 rollers .................................................................................................................$800.00
* Single stock support stand with one roller, movable.............................................................................................$325.00
* Air System (cleans and cools blade) ....................................................................................................................$325.00
* Crate Fee ..................................................................................................................................................................... $325.00
DELIVERY:
SUBJECT TO STOCK
