| Working Area | 3000 x 1500 mm (10x5ft) |
| X-Axis Travel | 1524 (BLT6 series and above large cutting head 1504) |
| Y-Axis Travel | 3048 (BLT6 series and above large cutting head 3028) |
| Z AXIS TRAVEL | 270 (10.6) |
| X/Y Axis Positioning Accuracy | 0.03mm/m (0.0012in/ft) |
| X/Y Repositioning Accuracy | 0.02mm (0.0008in) |
| Maximum composite positioning velocity and acceleration | 170m/min (6693 IPM) 2.8G |
| Maximum Cutting Acceleration | 1.5G |
| Machining Low-pass filtering | 7HZ |
| Maximum Cutting Thickness | 30mm (1.18in) |
| Cutting Slit Width | 0.1mm-0.5mm (Measured for plates less than 3mm thick) 0.0004-0.020 in (Measured for plates less than 0.118in thick) |
| Cutting surface roughness | Ra3.2um-Ra25.4um (Measured for plate thickness below 3mm) Ra125 uin- Ra1000 uin (Measured for sheets thinner than 0.118in) |
| Floor Size | 10120*3500 (33.2*11.5ft) |
| Mainframe Dimension | 9120*2300*2350 (29.92*7.55*7.71ft) |
| Weight | 5600(12346lb) |
| Screen Size | 27" LCD |
| Transmission Mode | Rack and pinion dual drive |
| Dual Table Loading Capacity | 2.9(Ton)(6393lb) |
| Final Assembly Electromechanical capacity | 3000W , 6000W , 12000W |
| Power Requirments | AC380V,50/60H;3P+N+PE |
| Table Power Protection Level | IP51 |
Our knowledgeable staff will assist you with all of you questions.
