| Type (Auto, Manual, Semi) | semi |
| Bed Height | 33.47 inches |
| Blade Length | 240 inches |
| Blade Speed | 150-300 SFPM |
| Blade Speeds | 50-300 SFPM |
| Blade Wheel Diameter | 22.83 inches |
| Cutting Capacity (W x D) | 18" x 33" |
| Drive | EVS |
| Electrics | 7-1/2HP, 230V, 3Ph |
| Floor Space Required | 110" x 74" x 82-5/8" |
| Maximum Vise Opening | 31.5 inches |
| Motor | 7.5 HP |
| Net Weight | 5060 pounds |
| Overall Dimensions (L x W x H) | 110" x 75" x 83" |
| Prewired Voltage | 230 Volts |
| Rectangle at 45° | 18" x 20.81" |
| Rectangle at 60° | 18" x 14.91" |
| Rectangle at 90° | 18" x 31.5" |
| Round at 45° | 18 inches |
| Round at 60° | 18 inches |
| Round at 90° | 15 inches |
| Shipping Weight | 5500 pounds |
| Square at 45° | 18" x 18" |
| Square at 60° | 15" x 15" |
| Square at 90° | 18" x 18" |
| Throat Depth | 18 inches |
| Blade Size | 1.61" x 0.051" x 240" |
| Coolant Pump Motor | 1/8HP, 230V, 3PH |
| Mitering Angle Motor | 1/5HP, 460V, 3Ph |
| Oil Pump Motor | 1HP, 230V, 3Ph |
