« T-slot across front edge of brake bed

« 8” Deep gaps in side frames for bending longer lengths with larger flanges

« The parallelism between moving upper beam and fixed lower beam during is ensured by two precision proportional valves. controlled by the CNC control (axes Y1 and Y2).

« Motor and controls. Electrics for 3/60/220/440. Low voltage at the controls.  Emergency stop palm button.

« All Components Readily Available from Your Local Suppliers

« All component’s original manufacturer and part number are included in machine manual so you will never have problems locating parts.

« Typical 20-30 Year Lifetime

« Manual ram clamps for American style tooling.Available with Wila quick-change ram clamping optionally.

« Two day onsite training in contiguous U.S.

« 29” travel, X axis, servo gauging system w/manual R/Z
840 2D Graphical Control
 « Multi-touch touchscreen allowing operator to draw parts/tooling with finger/stylus
« Remote support/service and diagnostics via ethernet
« Windows 10 operating system
« Fully 2D Graphical control w/touchscreen
« 15” color screen on pendant
« Crowning correction in degrees (crowning sold separately)
« 2D identification of best bending sequences
« 2D graphical Offline software for desktop programming
« 2D collision detection
« Unlimited job storage via USB & Ethernet
« X, Y, R, Z1-Z2, X-Prime programmability
« Readily accepts most tooling files
« 30,000 hard drive programs
« Programmable delay & retract at pinch point
« Direct connection of optional Mitutoyo protractor and Anglecheck devices to allow process angle measurement
« Inch/mm conversion
« Auto return of ram included
« Low speed retract included
« Dwell/decompression included
« Onsite training at customer's facility
Readily available
Off-the shelf controls
Available anywhere in the world

« Y1-Y2-Axes +,- .0004” ram repeatability and programming of the ram position (vertical) as well as tilting +, - .750” (or more) for tapered bends (cones)

« Front Gauging 2 each – 24” Front support arms with imbedded scales also includes t-slot across front edge

« Groove in Bed and Ram Clamps for American Style Tooling (other styles avail.)

« 5 Year Parts Warranty + 5 Year Limited Onsite Labor Warranty

« Lifetime Telephone Support at No Charge

« Manifold centralized lube system

« Hand/Foot sequence w/footswitch for single operator

« T-slot across front edge of brake bed

« UL508A compliant

« Programmable tonnage via the 840 control

« Heavy duty, X axis, servo gauging system with 29” travel, manual R and manual Z

« Training: 2 Day Onsite training for operation, maintenance, safety and insure proper physical installation of machine.

Note: machine must be fully leveled, bolted to floor, oil in reservoir and powered electrically prior to arrival of technician.($1,000.00 per day for additional days)

OPTIONAL FEATURES:
August 2025  Model EV Y1-Y2 Options Pages-90 ton to 550 ton up to 20'.pdf
