| Capacity, Mild Steel | 14 ga / 2,0mm |
| Capacity with bending support angle removed, mild steel | 18 ga / 1,25mm |
| Bending Length | 120" / 3,048mm |
| Maximum Lift of Beam | 2.25" / 57mm |
| Front to Rear Adjustment | 1/2" / 13mm |
| Maximum Depth of Box | 6" / 152.4 mm |
| Tooling Widths | 3", 4" and 5" / 76.3, 101.6 and 127mm |
| Minimum Reverse Bend | 1/4" / 6mm |
| Minimum Flange in Capacity Material | 1" / 25mm |
| Dimensions, Counterweights in place, L x W x H | 161" x 53" x 60" / 4090 x 1347 x 1524mm |
| Weight | 3675 pounds |
