SPECIFICATIONS:
NOMINAL ROLL DIAMETER -------------------- 9 in
RATED ROLLING CAPACITY (MILD STEEL) ------ .33” mild steel plate to 36” diameter x 8' wide
MOTOR ------------------------------------ 10 HP
VOLTAGE ---------------------------------- 230/460Volt/ 3PH TEFC
APPROXIMATE WEIGHT ----------------------- 8,800LBS
APPROX DIMENSIONS ---------------------- 155" x 31" x 42"
FEATURES:
• 1045 carbon steel rolls
• Hydraulic driven roll which provides instant start, stop, and reverse
• NEMA 12 control cabinet with fused power supply
• Electrics meet NFPA 79 specifications
• 230/460-volt 3 phase 50/60 hertz electrics (specify voltage when ordering)
• Variable frequency drive providing infinitely variable speed from 0-22 FPM and electronic overload protection
• Two roll drive
• SKF spherical roller bearings on all main bearings
• LSHT type hydraulic drive motor with high volumetric and overall efficiency
• Safety cable around perimeter of machine
• Beta 3.2 rolling console control. Push button control of main functions and 3 digital readouts to show the position of the 3 lower rolls.
• Rolls directly driven or through planetary gear type speed reducers
• Machine sets directly on level floor
• Ability to roll symmetrical steel sections without additional attachments
• Hydraulic operated drop end support
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
• Cone Attachment -$2,150
• Heavy Duty Cone Attachment -$4,000
• Hardened Only Rolls -$7,200
• Hardened and Polished Rolls -$13,100
• Circular Grooves 3/8, 1/2, 5/8 -$1,000
• Additional Starting Groove -$450
• Side Support Each -$9,050
• Overhead Support 12' Max -$10,000
• Foot Switch (rotation/pinch) -$1,000
• Pre 3.2 Control -$10,700
DELIVERY:
30-32 Weeks
